How fast you can spin up a VM in Azure Cloud? Have you experienced an azure cloud shell and terraform builder tool? Let’s quickly spin up a Linux VM using terraform code from Azure Cloud Shell. There are 100 ways to build the VM but this article just shows the robustness of the terraform and command line.
1.Login to Azure portal and then access https://shell.azure.com/.
2. Create terraform deployment file for Linux like below.
Assumptions: Deploying in to existing resource group, existing vnet, subnet
provider "azurerm" {
version = "~>2.0"
features {}
}
# Reference existing resource group
data "azurerm_resource_group" "main" {
name = "UArg"
}
# Reference existing vnet
data "azurerm_virtual_network" "main" {
name = "UAVnet"
resource_group_name = data.azurerm_resource_group.main.name
}
# Reference existing subnet
data "azurerm_subnet" "main" {
name = "test"
virtual_network_name = data.azurerm_virtual_network.main.name
resource_group_name = data.azurerm_resource_group.main.name
}
# Create network interface
resource "azurerm_network_interface" "main" {
name = "UAvm1-nic"
location = "westus2"
resource_group_name = data.azurerm_resource_group.main.name
ip_configuration {
name = "UAvm1-ip"
subnet_id = data.azurerm_subnet.main.id
private_ip_address_allocation = "Dynamic"
}
tags = {
environment = "UnixArena Terraform Demo"
}
}
#Create CentOS 7.5 virtual machince
resource "azurerm_linux_virtual_machine" "main" {
name = "UAvm1"
location = "westus2"
resource_group_name = data.azurerm_resource_group.main.name
network_interface_ids = [azurerm_network_interface.main.id]
size = "Standard_DS1_v2"
os_disk {
name = "UAvm1OSdisk"
caching = "ReadWrite"
storage_account_type = "Standard_LRS"
}
source_image_reference {
publisher = "OpenLogic"
offer = "CentOS"
sku = "7.5"
version = "latest"
}
computer_name = "myvm"
admin_username = "azureuser"
admin_password = "test@123"
disable_password_authentication = false
tags = {
environment = "UnixArena Terraform Demo"
}
}
3. Execute terraform plan to preview the deployment .
UA@Azure:~/clouddrive/terraform/linux_vm$ terraform plan
Refreshing Terraform state in-memory prior to plan...
The refreshed state will be used to calculate this plan, but will not be
persisted to local or remote state storage.
data.azurerm_resource_group.main: Refreshing state...
data.azurerm_virtual_network.main: Refreshing state...
data.azurerm_subnet.main: Refreshing state...
------------------------------------------------------------------------
An execution plan has been generated and is shown below.
Resource actions are indicated with the following symbols:
+ create
Terraform will perform the following actions:
# azurerm_linux_virtual_machine.main will be created
+ resource "azurerm_linux_virtual_machine" "main" {
+ admin_password = (sensitive value)
+ admin_username = "azureuser"
+ allow_extension_operations = true
+ computer_name = "myvm"
+ disable_password_authentication = false
+ id = (known after apply)
+ location = "westus2"
+ max_bid_price = -1
+ name = "UAvm1"
+ network_interface_ids = (known after apply)
+ priority = "Regular"
+ private_ip_address = (known after apply)
+ private_ip_addresses = (known after apply)
+ provision_vm_agent = true
+ public_ip_address = (known after apply)
+ public_ip_addresses = (known after apply)
+ resource_group_name = "UArg"
+ size = "Standard_DS1_v2"
+ tags = {
+ "environment" = "UnixArena Terraform Demo"
}
+ virtual_machine_id = (known after apply)
+ zone = (known after apply)
+ os_disk {
+ caching = "ReadWrite"
+ disk_size_gb = (known after apply)
+ name = "UAvm1OSdisk"
+ storage_account_type = "Standard_LRS"
+ write_accelerator_enabled = false
}
+ source_image_reference {
+ offer = "CentOS"
+ publisher = "OpenLogic"
+ sku = "7.5"
+ version = "latest"
}
}
# azurerm_network_interface.main will be created
+ resource "azurerm_network_interface" "main" {
+ applied_dns_servers = (known after apply)
+ dns_servers = (known after apply)
+ enable_accelerated_networking = false
+ enable_ip_forwarding = false
+ id = (known after apply)
+ internal_dns_name_label = (known after apply)
+ internal_domain_name_suffix = (known after apply)
+ location = "westus2"
+ mac_address = (known after apply)
+ name = "UAvm1-nic"
+ private_ip_address = (known after apply)
+ private_ip_addresses = (known after apply)
+ resource_group_name = "UArg"
+ tags = {
+ "environment" = "UnixArena Terraform Demo"
}
+ virtual_machine_id = (known after apply)
+ ip_configuration {
+ name = "UAvm1-ip"
+ primary = (known after apply)
+ private_ip_address = (known after apply)
+ private_ip_address_allocation = "dynamic"
+ private_ip_address_version = "IPv4"
+ subnet_id = "/subscriptions/585051ec-7aa0-48ab-a172-d1260ad72ee5/resourceGroups/UArg/providers/Microsoft.Network/virtualNetworks/UAVnet/subnets/test"
}
}
Plan: 2 to add, 0 to change, 0 to destroy.
------------------------------------------------------------------------
Note: You didn't specify an "-out" parameter to save this plan, so Terraform
can't guarantee that exactly these actions will be performed if
"terraform apply" is subsequently run.
UA@Azure:~/clouddrive/terraform/linux_vm$
4. If the preview of the deployment looks fine, execute terraform apply to create the VM.
UA@Azure:~/clouddrive/terraform/linux_vm$ terraform apply
data.azurerm_resource_group.main: Refreshing state...
data.azurerm_virtual_network.main: Refreshing state...
data.azurerm_subnet.main: Refreshing state...
An execution plan has been generated and is shown below.
Resource actions are indicated with the following symbols:
+ create
Terraform will perform the following actions:
# azurerm_linux_virtual_machine.main will be created
+ resource "azurerm_linux_virtual_machine" "main" {
+ admin_password = (sensitive value)
+ admin_username = "azureuser"
+ allow_extension_operations = true
+ computer_name = "myvm"
+ disable_password_authentication = false
+ id = (known after apply)
+ location = "westus2"
+ max_bid_price = -1
+ name = "UAvm1"
+ network_interface_ids = (known after apply)
+ priority = "Regular"
+ private_ip_address = (known after apply)
+ private_ip_addresses = (known after apply)
+ provision_vm_agent = true
+ public_ip_address = (known after apply)
+ public_ip_addresses = (known after apply)
+ resource_group_name = "UArg"
+ size = "Standard_DS1_v2"
+ tags = {
+ "environment" = "UnixArena Terraform Demo"
}
+ virtual_machine_id = (known after apply)
+ zone = (known after apply)
+ os_disk {
+ caching = "ReadWrite"
+ disk_size_gb = (known after apply)
+ name = "UAvm1OSdisk"
+ storage_account_type = "Standard_LRS"
+ write_accelerator_enabled = false
}
+ source_image_reference {
+ offer = "CentOS"
+ publisher = "OpenLogic"
+ sku = "7.5"
+ version = "latest"
}
}
# azurerm_network_interface.main will be created
+ resource "azurerm_network_interface" "main" {
+ applied_dns_servers = (known after apply)
+ dns_servers = (known after apply)
+ enable_accelerated_networking = false
+ enable_ip_forwarding = false
+ id = (known after apply)
+ internal_dns_name_label = (known after apply)
+ internal_domain_name_suffix = (known after apply)
+ location = "westus2"
+ mac_address = (known after apply)
+ name = "UAvm1-nic"
+ private_ip_address = (known after apply)
+ private_ip_addresses = (known after apply)
+ resource_group_name = "UArg"
+ tags = {
+ "environment" = "UnixArena Terraform Demo"
}
+ virtual_machine_id = (known after apply)
+ ip_configuration {
+ name = "UAvm1-ip"
+ primary = (known after apply)
+ private_ip_address = (known after apply)
+ private_ip_address_allocation = "dynamic"
+ private_ip_address_version = "IPv4"
+ subnet_id = "/subscriptions/585051ec-7aa0-48ab-a172-d1260ad72ee5/resourceGroups/UArg/providers/Microsoft.Network/virtualNetworks/UAVnet/subnets/test"
}
}
Plan: 2 to add, 0 to change, 0 to destroy.
Do you want to perform these actions?
Terraform will perform the actions described above.
Only 'yes' will be accepted to approve.
Enter a value: yes
azurerm_network_interface.main: Creating...
azurerm_network_interface.main: Creation complete after 2s [id=/subscriptions/585051ec-7aa0-48ab-a172-d1260ad72ee5/resourceGroups/UArg/providers/Microsoft.Network/networkInterfaces/UAvm1-nic]
azurerm_linux_virtual_machine.main: Creating...
azurerm_linux_virtual_machine.main: Still creating... [10s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [20s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [30s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [40s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [50s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [1m0s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [1m10s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [1m20s elapsed]
azurerm_linux_virtual_machine.main: Still creating... [1m30s elapsed]
azurerm_linux_virtual_machine.main: Creation complete after 1m37s [id=/subscriptions/585051ec-7aa0-48ab-a172-d1260ad72ee5/resourceGroups/UArg/providers/Microsoft.Compute/virtualMachines/UAvm1]
Apply complete! Resources: 2 added, 0 changed, 0 destroyed.
UA@Azure:~/clouddrive/terraform/linux_vm$
5. You can login to portal and check the newly created VM.
Hope this article is informative to you. Share it! Comment it!! Be sociable!!!
