Keystone provides the identify service in openstack which is responsible for user management. It tracks the openstack users and their permissions. It provides a catalog of available services with their API endpoints. OpenStack Identity Service needs to install on controller node. Keystone will use the database to store the information. So we need to configure the keystone service to use the locally installed Mysql DB. Before proceeding further, You need to understand the terms like User, credentials , Authentication, Token, Tenant, service, Endpoint and Role.
OpenStack Identity Service Installation : (Keystone) – Juno .
To select the specific version of openstack , please go through the article part 1.
1.Install the keystone Service on the openstack controller node, along with python-keystone client.
root@OSCTRL-UA:~# apt-get install keystone Reading package lists... Done Building dependency tree Reading state information... Done The following extra packages will be installed: libgmp10 libjs-jquery libjs-sphinxdoc libjs-underscore librabbitmq1 libyaml-0-2 python-amqp python-anyjson python-babel python-babel-localedata python-crypto python-decorator python-dns python-dogpile.cache python-dogpile.core python-eventlet python-formencode python-greenlet python-iso8601 python-jsonschema python-keystone python-keystoneclient python-kombu python-ldap python-librabbitmq python-lockfile python-lxml python-migrate python-mock python-netaddr python-oauthlib python-openid python-oslo.config python-oslo.messaging python-passlib python-paste python-pastedeploy python-pastedeploy-tpl python-pastescript python-pbr python-prettytable python-pycadf python-repoze.lru python-routes python-scgi python-setuptools python-sqlalchemy python-sqlalchemy-ext python-stevedore python-tempita python-tz python-webob python-yaml ssl-cert Suggested packages: javascript-common python-amqp-doc python-crypto-dbg python-crypto-doc python-egenix-mxdatetime python-greenlet-doc python-greenlet-dev python-greenlet-dbg python-memcache python-boto python-beanstalkc python-django python-kombu-doc python-pika python-pymongo python-ldap-doc python-pyasn1 python-lxml-dbg python-mock-doc ipython python-netaddr-docs python-pastewebkit libjs-mochikit libapache2-mod-wsgi libapache2-mod-python libapache2-mod-scgi python-pgsql python-flup python-cherrypy python-cheetah python-sqlalchemy-doc python-psycopg2 python-kinterbasdb python-pymssql python-webob-doc openssl-blacklist The following NEW packages will be installed: keystone libgmp10 libjs-jquery libjs-sphinxdoc libjs-underscore librabbitmq1 libyaml-0-2 python-amqp python-anyjson python-babel python-babel-localedata python-crypto python-decorator python-dns python-dogpile.cache python-dogpile.core python-eventlet python-formencode python-greenlet python-iso8601 python-jsonschema python-keystone python-keystoneclient python-kombu python-ldap python-librabbitmq python-lockfile python-lxml python-migrate python-mock python-netaddr python-oauthlib python-openid python-oslo.config python-oslo.messaging python-passlib python-paste python-pastedeploy python-pastedeploy-tpl python-pastescript python-pbr python-prettytable python-pycadf python-repoze.lru python-routes python-scgi python-setuptools python-sqlalchemy python-sqlalchemy-ext python-stevedore python-tempita python-tz python-webob python-yaml ssl-cert 0 upgraded, 55 newly installed, 0 to remove and 49 not upgraded. Need to get 7,722 kB of archives. After this operation, 44.7 MB of additional disk space will be used. Do you want to continue? [Y/n] y Get:1 http://in.archive.ubuntu.com/ubuntu/ trusty/main libgmp10 amd64 2:5.1.3+dfsg-1ubuntu1 [218 kB] Get:2 http://in.archive.ubuntu.com/ubuntu/ trusty/main librabbitmq1 amd64 0.4.1-1 [35.2 kB] Selecting previously unselected package python-dns. Preparing to unpack .../python-dns_2.3.6-3_all.deb ... Unpacking python-dns (2.3.6-3) ... Preparing to unpack .../python-ldap_2.4.10-1build1_amd64.deb ... Unpacking python-ldap (2.4.10-1build1) ... Selecting previously unselected package python-lxml. Preparing to unpack .../python-lxml_3.3.3-1ubuntu0.1_amd64.deb ... Unpacking python-lxml (3.3.3-1ubuntu0.1) ... Selecting previously unselected package python-oauthlib. <<<<<<<<<>>>>>>> Setting up python-scgi (1.13-1.1build1) ... Setting up python-sqlalchemy-ext (0.8.4-1build1) ... Setting up ssl-cert (1.0.33) ... Setting up python-keystoneclient (1:0.7.1-ubuntu1.2) ... Setting up keystone (1:2014.1.5-0ubuntu1) ... Generating RSA private key, 2048 bit long modulus ..............................+++ .......+++ e is 65537 (0x10001) Generating RSA private key, 2048 bit long modulus ................................................................................+++ ...............+++ e is 65537 (0x10001) Using configuration from /etc/keystone/ssl/certs/openssl.conf Check that the request matches the signature Signature ok The Subject's Distinguished Name is as follows countryName :PRINTABLE:'US' stateOrProvinceName :ASN.1 12:'Unset' localityName :ASN.1 12:'Unset' organizationName :ASN.1 12:'Unset' commonName :ASN.1 12:'www.example.com' Certificate is to be certified until Sep 17 20:00:57 2025 GMT (3650 days) Write out database with 1 new entries Data Base Updated keystone start/running, process 7709 Processing triggers for libc-bin (2.19-0ubuntu6.6) ... Processing triggers for ureadahead (0.100.0-16) ... root@OSCTRL-UA:~#
According to wiki.openstack.org
Check the installed package version details ,
root@OSCTRL-UA:~# dpkg -l | grep keystone ii keystone 1:2014.2.3-0ubuntu1~cloud0 all OpenStack identity service - Daemons ii python-keystone 1:2014.2.3-0ubuntu1~cloud0 all OpenStack identity service - Python library ii python-keystoneclient 1:0.10.1-0ubuntu1.1~cloud0 all Client library for OpenStack Identity API ii python-keystonemiddleware 1.0.0-1ubuntu0.14.10.2~cloud0 all Middleware for OpenStack Identity (Keystone) - Python 2.x root@OSCTRL-UA:~#
Compare the table above & command output to know the Openstack release name. In our case , it is using “Juno”.
2. Specify the location of the database in the configuration file. In this guide, we use a MySQL database on the controller node with the username keystone. Replace KEYSTONE_DBPASS with a suitable password for the database user. Edit the keystone.conf like below. (Refer Part 2 to know the pre-defined password)
root@OSCTRL-UA:~# cat /etc/keystone/keystone.conf |grep -v "#" |grep connection connection = mysql://keystone:keydb123@OSCTRL-UA/keystone root@OSCTRL-UA:~#
User=keystone
Password=keydb123
Controller HostName = OSCTRL-UA
3.Delete the default SQLite database which is created automatically during the installation.
root@OSCTRL-UA:~# rm /var/lib/keystone/keystone.db root@OSCTRL-UA:~#
4. Configure the Mysql database for keystone service. First you need to login as Mysql root with configured password. (Refer Part to know the Mysql root password)
root@OSCTRL-UA:~# mysql -u root -pstack Welcome to the MySQL monitor. Commands end with ; or \g. Your MySQL connection id is 48 Server version: 5.5.44-0ubuntu0.14.04.1 (Ubuntu) Copyright (c) 2000, 2015, Oracle and/or its affiliates. All rights reserved. Oracle is a registered trademark of Oracle Corporation and/or its affiliates. Other names may be trademarks of their respective owners. Type 'help;' or '\h' for help. Type '\c' to clear the current input statement. mysql> CREATE DATABASE keystone; Query OK, 1 row affected (0.00 sec) mysql> GRANT ALL PRIVILEGES ON keystone.* TO 'keystone'@'localhost' IDENTIFIED BY 'keydb123'; Query OK, 0 rows affected (0.00 sec) mysql> GRANT ALL PRIVILEGES ON keystone.* TO 'keystone'@'%' IDENTIFIED BY 'keydb123'; Query OK, 0 rows affected (0.00 sec) mysql> exit Bye root@OSCTRL-UA:~#
In Mysql ,we have just created the table called “keystone” and grated all privileges to “keystone” user . keystone database user password is “keydb123”.
5. Populate the Identity service(keystone) database.
root@OSCTRL-UA:~# su -s /bin/sh -c "keystone-manage db_sync" keystone root@OSCTRL-UA:~#
6. Define an authorization token to use as a shared secret between the Identity Service and other OpenStack services. Use openssl to generate a random token and store it in the keystone configuration file.
root@OSCTRL-UA:~# openssl rand -hex 10 a5d5bc4c4f358460ddc0 root@OSCTRL-UA:~# vi /etc/keystone/keystone.conf root@OSCTRL-UA:~# head -3 /etc/keystone/keystone.conf [DEFAULT] # A "shared secret" between keystone and other openstack services admin_token = a5d5bc4c4f358460ddc0 root@OSCTRL-UA:~#
7. Configure the log directory for keystone service. Edit the /etc/keystone/keystone.conf file and update the [DEFAULT] section.
root@OSCTRL-UA:~# vi /etc/keystone/keystone.conf root@OSCTRL-UA:~# head -4 /etc/keystone/keystone.conf [DEFAULT] # A "shared secret" between keystone and other openstack services admin_token = a5d5bc4c4f358460ddc0 log_dir = /var/log/keystone root@OSCTRL-UA:~#
8.Restart the keystone service to take effect of new settings.
root@OSCTRL-UA:~# service keystone restart keystone stop/waiting keystone start/running, process 8458 root@OSCTRL-UA:~#
9.Add cronjob to perform the expired tokens clean up. By default keystone service stores the expired token in the database indefinitely. This will increase the database size and may reduce the performance. So its better to purge the expired tokens hourly basis.
root@OSCTRL-UA:~# (crontab -l 2>&1 | grep -q token_flush) || echo '@hourly /usr/bin/keystone-manage token_flush >/var/log/keystone/keystone-tokenflush.log 2>&1' >> /var/spool/cron/crontabs/root root@OSCTRL-UA:~# crontab -l @hourly /usr/bin/keystone-manage token_flush >/var/log/keystone/keystone-tokenflush.log 2>&1 root@OSCTRL-UA:~#
Configure Apache HTTP server:
1. Install Apache server.
root@OSCTRL-UA:~# apt-get install apache2 Reading package lists... Done Building dependency tree Reading state information... Done The following extra packages will be installed: apache2-bin apache2-data libapr1 libaprutil1 libaprutil1-dbd-sqlite3 libaprutil1-ldap Suggested packages: apache2-doc apache2-suexec-pristine apache2-suexec-custom apache2-utils The following NEW packages will be installed: apache2 apache2-bin apache2-data libapr1 libaprutil1 libaprutil1-dbd-sqlite3 libaprutil1-ldap 0 upgraded, 7 newly installed, 0 to remove and 0 not upgraded. Need to get 1,270 kB of archives. After this operation, 5,238 kB of additional disk space will be used. Do you want to continue? [Y/n] y
2.Install mod-wsgi for apache2.
root@OSCTRL-UA:~# apt-get install libapache2-mod-wsgi Reading package lists... Done Building dependency tree Reading state information... Done The following NEW packages will be installed: libapache2-mod-wsgi 0 upgraded, 1 newly installed, 0 to remove and 0 not upgraded. Need to get 67.4 kB of archives. After this operation, 248 kB of additional disk space will be used. Get:1 http://in.archive.ubuntu.com/ubuntu/ trusty-updates/main libapache2-mod-wsgi amd64 3.4-4ubuntu2.1.14.04.2 [67.4 kB] Fetched 67.4 kB in 3s (19.6 kB/s) Selecting previously unselected package libapache2-mod-wsgi. (Reading database ... 95781 files and directories currently installed.) Preparing to unpack .../libapache2-mod-wsgi_3.4-4ubuntu2.1.14.04.2_amd64.deb ... Unpacking libapache2-mod-wsgi (3.4-4ubuntu2.1.14.04.2) ... Setting up libapache2-mod-wsgi (3.4-4ubuntu2.1.14.04.2) ... apache2_invoke: Enable module wsgi * Restarting web server apache2
3. Edit the “/etc/apache2/apache2.conf” and configure the ServerName option to reference the controller node.
root@OSCTRL-UA:~# cat /etc/apache2/apache2.conf |grep ServerName ServerName OSCTRL-UA root@OSCTRL-UA:~#
4. Just create the blank file like below.
#touch /etc/apache2/sites-available/wsgi-keystone.conf
5. Enable the Identity service virtual hosts.
# ln -s /etc/apache2/sites-available/wsgi-keystone.conf /etc/apache2/sites-enabled
6.Create the directory structure for the WSGI components under /var/www/cgi-bin/
# mkdir -p /var/www/cgi-bin/keystone
7. Copy WSGI components.
root@OSCTRL-UA:~# curl http://git.openstack.org/cgit/openstack/keystone/plain/httpd/keystone.py?h=stable/juno | tee /var/www/cgi-bin/keystone/main /var/www/cgi-bin/keystone/admin
8.Adjust ownership and permissions on this directory and the files in it.
# chown -R keystone:keystone /var/www/cgi-bin/keystone # chmod 755 /var/www/cgi-bin/keystone/*
9. Stop the keystone and restart apache2 & keystone.
root@OSCTRL-UA:~# service keystone stop root@OSCTRL-UA:~# service apache2 restart root@OSCTRL-UA:~# service keystone start
Click on Page 2 to continue ….
Define Users, Tenants and Roles Using keystone Command:
Once you have installed and configured the keystone service , setup the users , tenants(Projects) and roles for your environment. Before running any keystone related commands, define the environment variables “ADMIN_TOKEN”, “OS_SERVICE_TOKEN” and “OS_SERVICE_ENDPOINT” instead of giving these parameters in each keystone command. These environment variable helps to reduce command length.
- Set the environment variable for for keystone service.
root@OSCTRL-UA:~#export ADMIN_TOKEN=a5d5bc4c4f358460ddc0 root@OSCTRL-UA:~#export OS_SERVICE_TOKEN=$ADMIN_TOKEN root@OSCTRL-UA:~#export OS_SERVICE_ENDPOINT=http://OSCTRL-UA:35357/v2.0
Refer step 6 to know the ADMIN_TOKEN value.
2. Create the user “admin” using the keystone command.
root@OSCTRL-UA:~# keystone user-create --name=admin --pass=admin123 --email=lingeshwaran.rangasamy@gmail.com +----------+----------------------------------+ | Property | Value | +----------+----------------------------------+ | email | lingeshwaran.rangasamy@gmail.com | | enabled | True | | id | d154aa743ab4405c80055236c47ed98f | | name | admin | | username | admin | +----------+----------------------------------+ root@OSCTRL-UA:~#
3. Create a new role called “admin”.
root@OSCTRL-UA:~# keystone role-create --name=admin +----------+----------------------------------+ | Property | Value | +----------+----------------------------------+ | id | 58d6701963044a609f9d3724295effcd | | name | admin | +----------+----------------------------------+ root@OSCTRL-UA:~#
4. Create a new tenant called “admin”.
root@OSCTRL-UA:~# keystone tenant-create --name=admin --description="Admin Tenant" +-------------+----------------------------------+ | Property | Value | +-------------+----------------------------------+ | description | Admin Tenant | | enabled | True | | id | d14d6a07f862482398b3e3e4e8d581c6 | | name | admin | +-------------+----------------------------------+ root@OSCTRL-UA:~#
5. Link the admin user, admin role, and admin tenant together using the user-role-add option.
root@OSCTRL-UA:~# keystone user-role-add --user=admin --tenant=admin --role=admin root@OSCTRL-UA:~#
6. By default, the Identity Service creates a special _member_ role. The OpenStack dashboard automatically grants access to users with this role. You will give the admin user access to this role in addition to the admin role. Link the admin user, _member_ role, and admin tenant.
root@OSCTRL-UA:~# keystone user-role-add --user=admin --role=_member_ --tenant=admin root@OSCTRL-UA:~#
7. Let’s create the normal user.
root@OSCTRL-UA:~# keystone user-create --name=lingesh --pass=ling123 --email=lingeshwaran.rangasamy@gmail.com +----------+----------------------------------+ | Property | Value | +----------+----------------------------------+ | email | lingeshwaran.rangasamy@gmail.com | | enabled | True | | id | 3f01d4f7aa9e477cb885334ab9c5929d | | name | lingesh | | username | lingesh | +----------+----------------------------------+ root@OSCTRL-UA:~#
8.Create the tenant called “lingesh”.
root@OSCTRL-UA:~# keystone tenant-create --name=lingesh --description="UnixArena Tenant" +-------------+----------------------------------+ | Property | Value | +-------------+----------------------------------+ | description | UnixArena Tenant | | enabled | True | | id | abe3af30f46b446fbae35a102457890c | | name | lingesh | +-------------+----------------------------------+ root@OSCTRL-UA:~#
9. Link the tenant lingesh with user “lingesh” . Here we are just assigning role as member.
root@OSCTRL-UA:~# keystone user-role-add --user=lingesh --role=_member_ --tenant=lingesh root@OSCTRL-UA:~#
Click on Page 3 to continue …….
Configure the Service tenant:
Openstack services also require tenant , role & users to interact with other openstack services. Each openstack services will create new users with admin privileges under this tenant.
root@OSCTRL-UA:~# keystone tenant-create --name=service --description="Service Tenant" +-------------+----------------------------------+ | Property | Value | +-------------+----------------------------------+ | description | Service Tenant | | enabled | True | | id | 332f6865332b45aa9cf0d79aacd1ae3b | | name | service | +-------------+----------------------------------+ root@OSCTRL-UA:~#
Define services and API endpoints.
By Defining services and API endpoints, keystone service can track which openstack services are deployed and where it is located on the network. We must register each service in our openstack installation. keystone’s “service-create & endpoint-create ” does the job for you.
1. We have to register keystone service itself on keystone.Create a service entry for the Identity Service.
root@OSCTRL-UA:~# keystone service-create --name=keystone --type=identity --description="OpenStack Identity" +-------------+----------------------------------+ | Property | Value | +-------------+----------------------------------+ | description | OpenStack Identity | | enabled | True | | id | cfa2859138ae4549919cbf2bfd06346f | | name | keystone | | type | identity | +-------------+----------------------------------+ root@OSCTRL-UA:~#
2. Create the API endpoint for identify service. When you specify an endpoint, you provide URLs for the public API, internal API, and admin API along with the controller’s host name. Admin API uses the different port than other API’s. You require service ID to create API endpoint.
You can take the service ID from previous step or you can get it using below command.
root@OSCTRL-UA:~# keystone service-list | awk '/ identity / {print $2}'
cfa2859138ae4549919cbf2bfd06346f
root@OSCTRL-UA:~#
Create the API endpoint for identify service.
root@OSCTRL-UA:~# keystone endpoint-create --service-id=$(keystone service-list | awk '/ identity / {print $2}') --publicurl=http://OSCTRL-UA:5000/v2.0 --internalurl=http://OSCTRL-UA:5000/v2.0 --adminurl=http://OSCTRL-UA:35357/v2.0
+-------------+----------------------------------+
| Property | Value |
+-------------+----------------------------------+
| adminurl | http://OSCTRL-UA:35357/v2.0 |
| id | 7dbbfe1b14c343048c01e672426154ed |
| internalurl | http://OSCTRL-UA:5000/v2.0 |
| publicurl | http://OSCTRL-UA:5000/v2.0 |
| region | regionOne |
| service_id | cfa2859138ae4549919cbf2bfd06346f |
+-------------+----------------------------------+
root@OSCTRL-UA:~#
You need to create an additional endpoint for each openstack services.
Verify the Keystone Installation:
1. Unset the variables.
root@OSCTRL-UA:~# unset OS_SERVICE_TOKEN OS_SERVICE_ENDPOINT
2. Execute the command below to verify the identify service.
root@OSCTRL-UA:~# keystone --os-username=admin --os-password=admin123 --os-auth-url=http://OSCTRL-UA:35357/v2.0 token-get +----------+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ | Property | Value | +----------+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ | expires | 2015-09-21T19:21:55Z | | id | 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-s3REVULvtKeUuW1UmD+wYOckmZWwRCS1zRIfKk+vMjTo+eperKH+9CMFCzrTxrQDBvWLHIaVtRXQ1RBSuOSXOGBOH-9ZIYYO827aT576ivsQUoJWyFwrRN8nlvEGftr2VHzlJk3bvjnjs | | user_id | d154aa743ab4405c80055236c47ed98f | +----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ root@OSCTRL-UA:~#
You have received a token paired with your user ID “admin”. This verifies that the Identity(keystone) Service is running on the expected endpoint and that your user account is established with the expected credentials.
3. Create the source file to reduce the command length.
root@OSCTRL-UA:~# cat admin.rc export OS_USERNAME=admin export OS_PASSWORD=admin123 export OS_TENANT_NAME=admin export OS_AUTH_URL=http://OSCTRL-UA:35357/v2.0 root@OSCTRL-UA:~#
4. Source the file which you have created in the previous step.
root@OSCTRL-UA:~# source admin.rc root@OSCTRL-UA:~#
5.Run a command what you have in step 2 . Since, we have sourced the environment variables , you can simply run command without specifying the user credentials & OS Auth URL.
root@OSCTRL-UA:~# keystone token-get
6. Verify the admin account privileges by listing the keystone users.
root@OSCTRL-UA:~# keystone user-list +----------------------------------+---------+---------+----------------------------------+ | id | name | enabled | email | +----------------------------------+---------+---------+----------------------------------+ | d154aa743ab4405c80055236c47ed98f | admin | True | lingeshwaran.rangasamy@gmail.com | | 3f01d4f7aa9e477cb885334ab9c5929d | lingesh | True | lingeshwaran.rangasamy@gmail.com | +----------------------------------+---------+---------+----------------------------------+ root@OSCTRL-UA:~#
7. Let list the roles of each account.
root@OSCTRL-UA:~# keystone user-role-list --user admin --tenant admin +----------------------------------+----------+----------------------------------+----------------------------------+ | id | name | user_id | tenant_id | +----------------------------------+----------+----------------------------------+----------------------------------+ | 9fe2ff9ee4384b1894a90878d3e92bab | _member_ | d154aa743ab4405c80055236c47ed98f | d14d6a07f862482398b3e3e4e8d581c6 | | 58d6701963044a609f9d3724295effcd | admin | d154aa743ab4405c80055236c47ed98f | d14d6a07f862482398b3e3e4e8d581c6 | +----------------------------------+----------+----------------------------------+----------------------------------+ root@OSCTRL-UA:~#
user_id must match for keystone user-list command and keystone user-role-list command output. The admin role is listed for that user, for the related tenant, this verifies that your user account has the admin role, which matches the role used in the Identity Service policy.json file.
Hope this article is informative to you .
