How to set up Red Hat Openshift 4.x in Desktop/Laptop? Are you looking for a cost-effective solution to get the OCP 4.x lab environment? If yes, then this article is for you. Kubernetes is growing at a rapid pace and organizations are started using microservices more and more. When it comes to Kubernetes, Openshift stands out with its enterprise capabilities and security. Red Hat is now an IBM company that keeps on improving the products and installation setup of openshift. OCP 4.x installation is completely different from OCP 3.x. In OCP 4.x, they have moved away from ansible-based deployment, and it ships with installer binary. This binary has the capabilities to spin up the openshift environment in ON-PREM and Cloud directly.
OCP 4.x offers multiple ways to set up the single node cluster. In this article, we will be looking to the “Code Ready Containers (CRC)” to have local openshift instances for testing and local development.
CodeReady Containers is the quickest way to get started building OpenShift clusters. It is designed to run on a local computer to simplify setup and testing and emulate the cloud development environment locally with all of the tools needed to develop container-based applications. Whatever your programming language, CRC will host your application. CodeReady Containers brings a minimal, preconfigured OpenShift 4.x cluster to your local PC without the need for a server-based infrastructure. With CodeReady Containers (CRC), you can create microservices, build them into images, and run them in Kubernetes-hosted containers, right on your laptop or desktop running Linux, macOS, or Windows 10.
Is it possible to use AWS EC2 or Azure Virtual machine to set up CRC?
kindly note, CRC requires Intel-VT/AMD-v technology on the processor and it works only with x86 based processors. At present, it doesn’t support the Apple Mac M1 chip. CRC environment can’t be hosted in Amazon EC2 or Azure Virtual Machine since those are already virtualized instances. Basically, CRC doesn’t support nested virtualized environments. Cloud bare-metal instances support CRC but it is a very costly solution for a personal LAB environment.
Requirements
The general requirements for CodeReady Containers are:
- OS: CentOS 8x/RHEL 8x/Fedora (latest 2 releases)
- Download: pull-secret
- Login: Red Hat Account
The physical requirements include: (VM specs)
- Four virtual CPUs (vCPUs)
- 9-10 GB of memory (RAM)
- 40 GB of storage space
- Enable VT-x in hypervisor settings. Intel-VT/AMD-v must be enabled in the system BIOS first.
Example:
Installation
Here is the step-by-step process to start the openshift single node cluster on your workstation.
1. Install VMware workstation(Licensed)/ VMware workstation player (Free for personal use). If you are familiar with virtual box, you can use that as well.
2. Download Red Hat 8.5 minimal boot ISO. Ensure you have a Red Hat developer account for subscription registration.
3. Create a new virtual machine as per the specs given above. Once the VM is created, install Red Hat 8.x on that VM. Ensure that system is registered with Red Hat.
+-------------------------------------------+
Installed Product Status
+-------------------------------------------+
Product Name: Red Hat Enterprise Linux for x86_64
Product ID: 479
Version: 8.5
Arch: x86_64
Status: Subscribed
Status Details:
Starts: 03/17/2022
Ends: 05/16/2022
[lingesh@okd4 ~]$
4. Once the installation is completed, log in with a normal user and download CRC.
[lingesh@okd4 ~]$ mkdir crc [lingesh@okd4 ~]$ cd crc/ [lingesh@okd4 crc]$ wget https://mirror.openshift.com/pub/openshift-v4/clients/crc/latest/crc-linux-amd64.tar.xz --2022-03-18 09:59:48-- https://mirror.openshift.com/pub/openshift-v4/clients/crc/latest/crc-linux-amd64.tar.xz Resolving mirror.openshift.com (mirror.openshift.com)... 52.85.187.62, 52.85.187.66, 52.85.187.121, ... Connecting to mirror.openshift.com (mirror.openshift.com)|52.85.187.62|:443... connected. HTTP request sent, awaiting response... 307 Temporary Redirect Saving to: ‘crc-linux-amd64.tar.xz’ crc-linux-amd64.tar.xz 100%[=============================================>] 22.75M 1.22MB/s in 16s 2022-03-18 10:00:08 (1.39 MB/s) - ‘crc-linux-amd64.tar.xz’ saved [23853556/23853556] [lingesh@okd4 crc]$
5. Untar the binaries and move the “crc” binary to “/home/USER_HOME/crc” directory.
[lingesh@okd4 crc]$ tar -xvf crc-linux-amd64.tar.xz crc-linux-2.0.1-amd64/ crc-linux-2.0.1-amd64/LICENSE crc-linux-2.0.1-amd64/crc [lingesh@okd4 crc]$ ls -lrt total 23296 drwxr-xr-x. 2 lingesh lingesh 32 Mar 14 07:54 crc-linux-2.0.1-amd64 -rw-rw-r--. 1 lingesh lingesh 23853556 Mar 14 08:51 crc-linux-amd64.tar.xz [lingesh@okd4 crc]$ mv crc-linux-2.0.1-amd64/crc . [lingesh@okd4 crc]$ ls -lrt total 96576 -rwxr-xr-x. 1 lingesh lingesh 75037110 Mar 14 07:54 crc -rw-rw-r--. 1 lingesh lingesh 23853556 Mar 14 08:51 crc-linux-amd64.tar.xz drwxr-xr-x. 2 lingesh lingesh 21 Mar 18 10:00 crc-linux-2.0.1-amd64 [lingesh@okd4 crc]$ rm -rf crc-linux-*
6. Make the “crc” binary executable.
[lingesh@okd4 crc]$ chmod +x crc [lingesh@okd4 crc]$ export PATH=$PATH:/home/lingesh/crc
7. Set up the cluster.
[lingesh@okd4 ~]$ crc setup INFO Using bundle path /home/lingesh/.crc/cache/crc_libvirt_4.10.3_amd64.crcbund le INFO Checking if running as non-root INFO Checking if running inside WSL2 INFO Checking if crc-admin-helper executable is cached INFO Checking for obsolete admin-helper executable INFO Checking if running on a supported CPU architecture INFO Checking minimum RAM requirements INFO Checking if crc executable symlink exists INFO Checking if Virtualization is enabled INFO Checking if KVM is enabled INFO Checking if libvirt is installed INFO Checking if user is part of libvirt group INFO Checking if active user/process is currently part of the libvirt group INFO Checking if libvirt daemon is running INFO Checking if a supported libvirt version is installed INFO Checking if crc-driver-libvirt is installed INFO Checking crc daemon systemd service INFO Checking crc daemon systemd socket units INFO Setting up crc daemon systemd socket units INFO Checking if systemd-networkd is running INFO Checking if NetworkManager is installed INFO Checking if NetworkManager service is running INFO Checking if /etc/NetworkManager/conf.d/crc-nm-dnsmasq.conf exists INFO Writing Network Manager config for crc INFO Using root access: Writing NetworkManager configuration to /etc/NetworkMana ger/conf.d/crc-nm-dnsmasq.conf INFO Using root access: Changing permissions for /etc/NetworkManager/conf.d/crc- nm-dnsmasq.conf to 644 INFO Using root access: Executing systemctl daemon-reload command INFO Using root access: Executing systemctl reload NetworkManager INFO Checking if /etc/NetworkManager/dnsmasq.d/crc.conf exists INFO Writing dnsmasq config for crc INFO Using root access: Writing NetworkManager configuration to /etc/NetworkMana ger/dnsmasq.d/crc.conf INFO Using root access: Changing permissions for /etc/NetworkManager/dnsmasq.d/c rc.conf to 644 INFO Using root access: Executing systemctl daemon-reload command INFO Using root access: Executing systemctl reload NetworkManager INFO Checking if libvirt 'crc' network is available INFO Setting up libvirt 'crc' network INFO Checking if libvirt 'crc' network is active INFO Starting libvirt 'crc' network INFO Checking if CRC bundle is extracted in '$HOME/.crc' INFO Checking if /home/lingesh/.crc/cache/crc_libvirt_4.10.3_amd64.crcbundle exists INFO Getting bundle for the CRC executable INFO Downloading crc_libvirt_4.10.3_amd64.crcbundle 3.02 GiB / 3.02 GiB [--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------] 100.00% 2.13 MiB p/s INFO Uncompressing /home/lingesh/.crc/cache/crc_libvirt_4.10.3_amd64.crcbundle crc.qcow2: 12.51 GiB / 12.51 GiB [--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------] 100.00% oc: 117.14 MiB / 117.14 MiB [-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------] 100.00% Your system is correctly setup for using CodeReady Containers. Use 'crc start' to start the instance [lingesh@okd4 ~]$
8. Download pull secret from the Redhat portal.
9. Start the cluster using the downloaded pull secret. I have copied the pull secret from the portal and created the file manually.
[lingesh@okd4 ~]$ vi pull_secret [lingesh@okd4 ~]$ crc start -p ~/pull_secret INFO Checking if running as non-root INFO Checking if running inside WSL2 INFO Checking if crc-admin-helper executable is cached INFO Checking for obsolete admin-helper executable INFO Checking if running on a supported CPU architecture INFO Checking minimum RAM requirements INFO Checking if crc executable symlink exists INFO Checking if Virtualization is enabled INFO Checking if KVM is enabled INFO Checking if libvirt is installed INFO Checking if user is part of libvirt group INFO Checking if active user/process is currently part of the libvirt group INFO Checking if libvirt daemon is running INFO Checking if a supported libvirt version is installed INFO Checking if crc-driver-libvirt is installed INFO Checking crc daemon systemd socket units INFO Checking if systemd-networkd is running INFO Checking if NetworkManager is installed INFO Checking if NetworkManager service is running INFO Checking if /etc/NetworkManager/conf.d/crc-nm-dnsmasq.conf exists INFO Checking if /etc/NetworkManager/dnsmasq.d/crc.conf exists INFO Checking if libvirt 'crc' network is available INFO Checking if libvirt 'crc' network is active INFO Loading bundle: crc_libvirt_4.10.3_amd64... INFO Creating CodeReady Containers VM for OpenShift 4.10.3... INFO Generating new SSH Key pair... INFO Generating new password for the kubeadmin user INFO Starting CodeReady Containers VM for OpenShift 4.10.3... INFO CodeReady Containers instance is running with IP 192.168.130.11 INFO CodeReady Containers VM is running INFO Updating authorized keys... INFO Check internal and public DNS query... INFO Check DNS query from host... INFO Verifying validity of the kubelet certificates... INFO Starting OpenShift kubelet service INFO Waiting for kube-apiserver availability... [takes around 2min] INFO Adding user's pull secret to the cluster... INFO Updating SSH key to machine config resource... INFO Waiting for user's pull secret part of instance disk... INFO Changing the password for the kubeadmin user INFO Updating cluster ID... INFO Updating root CA cert to admin-kubeconfig-client-ca configmap... INFO Starting OpenShift cluster... [waiting for the cluster to stabilize] INFO 4 operators are progressing: image-registry, network, openshift-controller-manager, service-ca INFO 4 operators are progressing: image-registry, network, openshift-controller-manager, service-ca INFO 4 operators are progressing: image-registry, network, openshift-controller-manager, service-ca INFO 4 operators are progressing: image-registry, network, openshift-controller-manager, service-ca INFO 3 operators are progressing: image-registry, openshift-controller-manager, service-ca INFO 2 operators are progressing: image-registry, openshift-controller-manager INFO 2 operators are progressing: image-registry, openshift-controller-manager INFO Operator openshift-controller-manager is progressing INFO Operator openshift-controller-manager is progressing INFO Operator openshift-controller-manager is progressing INFO 2 operators are progressing: authentication, openshift-controller-manager INFO Operator openshift-controller-manager is progressing INFO Operator openshift-controller-manager is progressing INFO All operators are available. Ensuring stability... INFO Operators are stable (2/3)... INFO Operators are stable (3/3)... INFO Adding crc-admin and crc-developer contexts to kubeconfig... Started the OpenShift cluster. The server is accessible via web console at: https://console-openshift-console.apps-crc.testing Log in as administrator: Username: kubeadmin Password: xRkvx-pAu3P-5G66Y-JcZH8 Log in as user: Username: developer Password: developer Use the 'oc' command line interface: $ eval $(crc oc-env) $ oc login -u developer https://api.crc.testing:6443 [lingesh@okd4 ~]$
11. Setup the environment for the “oc” command.
[lingesh@okd4 ~]$ crc oc-env export PATH="/home/lingesh/.crc/bin/oc:$PATH" # Run this command to configure your shell: # eval $(crc oc-env) [lingesh@okd4 ~]$ eval $(crc oc-env)
12. Login to the cluster using the oc command.
[lingesh@okd4 ~]$ oc login -u kubeadmin -p xRkvx-pAu3P-5G66Y-JcZH8 https://api.crc.testing:6443 Login successful. You have access to 64 projects, the list has been suppressed. You can list all projects with 'oc projects' Using project "default". [lingesh@okd4 ~]$
13. Check the running nodes and cluster version.
[lingesh@okd4 crc]$ oc get nodes NAME STATUS ROLES AGE VERSION crc-jw57j-master-0 Ready master,worker 11d v1.23.3+e419edf [lingesh@okd4 crc]$ oc cluster-info Kubernetes control plane is running at https://api.crc.testing:6443 To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'. [lingesh@okd4 crc]$
We have successfully set up a single node openshift cluster on the local workstation / Laptop using the hypervisors.
Openshift Web-GUI
is it possible to access the feature-rich Openshift web GUI on CRC environment ? yes. You can access it by following the steps.
1. Run the following command to launch the GUI.
[lingesh@okd4 ~]$ crc console Opening the OpenShift Web Console in the default browser... [lingesh@okd4 ~]$
2. Here is the OCP 4 GUI interface.
To find your OCP credentials, run the following command on the terminal.
[lingesh@okd4 ~]$ crc console --credentials To login as a regular user, run 'oc login -u developer -p developer https://api.crc.testing:6443'. To login as an admin, run 'oc login -u kubeadmin -p xRkvx-pAu3P-5G66Y-JcZH8 https://api.crc.testing:6443' [lingesh@okd4 ~]$
3. I have logged in using kubeadmin.
Known Errors:
1. While running crc setup, if you get the following error, then it’s likely you have switched to the user using “su – ” command.
[lingesh@okd4 ~]$
[root@okd4 ~]# su – lingesh
[lingesh@okd4 ~]$ crc setup
INFO Using bundle path /home/lingesh/.crc/cache/crc_libvirt_4.10.3_amd64.crcbundle
INFO Checking if running as non-root
Executing systemctl action failed: exit status 1: Failed to connect to bus: No such file or directory
2. If “crc setup “returns an error like “You need to enable virtualization on BIOS” , then you are trying to setup crc on,
- Cloud instances
- Older Machine which doesn’t comes with virtualization technology on the processors.
- Intel-VT / AMD-v is disabled on the BIOS.
[ec2-user@ip-172-31-46-0 crc]$ crc setup CodeReady Containers is constantly improving and we would like to know more about usage (more details at https://developers.redhat.com/article/tool-data-collection) Your preference can be changed manually if desired using 'crc config set consent-telemetry <yes/no>' Would you like to contribute anonymous usage statistics? [y/N]: y Thanks for helping us! You can disable telemetry with the command 'crc config set consent-telemetry no'. INFO Using bundle path /home/ec2-user/.crc/cache/crc_libvirt_4.10.3_amd64.crcbundle INFO Checking if running as non-root INFO Checking if running inside WSL2 INFO Checking if crc-admin-helper executable is cached INFO Caching crc-admin-helper executable INFO Using root access: Changing ownership of /home/ec2-user/.crc/bin/crc-admin-helper-linux INFO Using root access: Setting suid for /home/ec2-user/.crc/bin/crc-admin-helper-linux INFO Checking for obsolete admin-helper executable INFO Checking if running on a supported CPU architecture INFO Checking minimum RAM requirements INFO Checking if crc executable symlink exists INFO Creating symlink for crc executable INFO Checking if Virtualization is enabled INFO Setting up virtualization You need to enable virtualization in BIOS [ec2-user@ip-172-31-46-0 crc]$
3. Unable to start the cluster using “crc start” .
Error starting machine: Error in driver during machine start: unexpected libvirt status 3 : machine in the unknown state: getting ip during machine start
Check “libvirtd” status.
[root@okd4 ~]# systemctl status libvirtd
● libvirtd.service - Virtualization daemon
Loaded: loaded (/usr/lib/systemd/system/libvirtd.service; enabled; vendor preset: enabled)
Active: active (running) since Tue 2022-03-29 20:14:54 IST; 2h 33min ago
Docs: man:libvirtd(8)
https://libvirt.org
Main PID: 1441 (libvirtd)
Tasks: 21 (limit: 32768)
Memory: 60.4M
CGroup: /system.slice/libvirtd.service
├─1441 /usr/sbin/libvirtd --timeout 120
├─1807 /usr/sbin/dnsmasq --conf-file=/var/lib/libvirt/dnsmasq/default.conf --leasefile-ro --dhcp-script=/usr/libexec/libvirt_leaseshelper
├─1808 /usr/sbin/dnsmasq --conf-file=/var/lib/libvirt/dnsmasq/default.conf --leasefile-ro --dhcp-script=/usr/libexec/libvirt_leaseshelper
├─1878 /usr/sbin/dnsmasq --conf-file=/var/lib/libvirt/dnsmasq/crc.conf --leasefile-ro --dhcp-script=/usr/libexec/libvirt_leaseshelper
└─1879 /usr/sbin/dnsmasq --conf-file=/var/lib/libvirt/dnsmasq/crc.conf --leasefile-ro --dhcp-script=/usr/libexec/libvirt_leaseshelper
Mar 29 20:20:33 okd4 libvirtd[1441]: End of file while reading data: Input/output error
The above errors show that “crc” is unable to read/write on the filesystem. Check the system filesystem utilization.
[root@okd4 cache]# df -h Filesystem Size Used Avail Use% Mounted on devtmpfs 4.8G 0 4.8G 0% /dev tmpfs 4.8G 0 4.8G 0% /dev/shm tmpfs 4.8G 9.7M 4.8G 1% /run tmpfs 4.8G 0 4.8G 0% /sys/fs/cgroup /dev/mapper/rhel_okd4-root 35G 35G 296K 100% / /dev/nvme0n1p1 1014M 215M 800M 22% /boot tmpfs 976M 12K 976M 1% /run/user/42 tmpfs 976M 32K 976M 1% /run/user/1000 [root@okd4 cache]#
In this case, we can see that the root filesystem is full and requires cleanup.
4. Openshift is showing “starting” but API doesn’t respond to any of the “oc” commands. I am facing this issue whenever I use to hibernate the host.
[lingesh@okd4 ~]$ crc status CRC VM: Running OpenShift: Starting (v4.10.3) Podman: Disk Usage: 22.47GB of 32.74GB (Inside the CRC VM) Cache Usage: 16.83GB Cache Directory: /home/lingesh/.crc/cache [lingesh@okd4 ~]$
To resolve this issue, Stop the CRC with a force flag.
[lingesh@okd4 ~]$ crc stop --force INFO Stopping kubelet and all containers... INFO Stopping the instance, this may take a few minutes... Stopped the instance [lingesh@okd4 ~]$
Reboot the host operating system.
[lingesh@okd4 ~]$ sudo reboot [lingesh@okd4 ~]$ Remote side unexpectedly closed network connection
Start the CRC with debug flag.
[lingesh@okd4 ~]$ crc start --log-level debug DEBU CodeReady Containers version: 2.0.1+bf3b1a6 DEBU OpenShift version: 4.10.3 DEBU Podman version: 3.4.4 DEBU Running 'crc start' DEBU Total memory of system is 16573595648 bytes WARN A new version (2.11.0) has been published on https://developers.redhat.com/content-gateway/file/pub/openshift-v4/clients/crc/2.11.0/crc-linux-amd64.tar.xz DEBU Checking file: /home/lingesh/.crc/machines/crc/.crc-exist DEBU Found binary path at /home/lingesh/.crc/bin/crc-driver-libvirt DEBU Launching plugin server for driver libvirt DEBU Plugin server listening at address 127.0.0.1:44615 DEBU () Calling .GetVersion DEBU Using API Version 1 DEBU () Calling .SetConfigRaw
Hope this article is informative to you. If so, please share it with your professional network.
