Once you have configured the Solaris cluster , you have to add the quorum device for additional voting process. Without Quorum devices, cluster will be in installed mode. You can verify the status using “cluster show -t global | grep installmode” command.Each node in a configured cluster has one ( 1 ) quorum vote and cluster require minimum two vote to run the cluster.If any one node goes down, cluster won’t get 2 votes and it will panic second node also to avoid the data corruption on shared storage. To avoid this situation, we can make one small SAN disk as quorum device which can provide one vote.So that, if one node fails, system can still get two votes all the time on two node cluster.
Once you have configured the two node Solaris cluster, you can start configure the quorum device.
1.Check the cluster node status.
UASOL1:#clnode status === Cluster Nodes === --- Node Status --- Node Name Status --------- ------ UASOL2 Online UASOL1 Online UASOL1:#
2.You can see that ,currently cluster is in install mode.
# cluster show -t global | grep installmode installmode: enabled
3.Current cluster quorum status
UASOL1:#clq status
=== Cluster Quorum ===
--- Quorum Votes Summary from (latest node reconfiguration) ---
Needed Present Possible
------ ------- --------
1 1 1
--- Quorum Votes by Node (current status) ---
Node Name Present Possible Status
--------- ------- -------- ------
UASOL2 1 1 Online
UASOL1 0 0 Online
UASOL1:#
4.Make sure you have small size LUN is assigned to both the cluster node from SAN.
UASOL1:#echo |format
Searching for disks...done
AVAILABLE DISK SELECTIONS:
0. c1t0d0 VMware,-VMware Virtual -1.0 cyl 1824 alt 2 hd 255 sec 63
/pci@0,0/pci15ad,1976@10/sd@0,0
1. c1t1d0 VMware,-VMware Virtual -1.0 cyl 508 alt 2 hd 64 sec 32
/pci@0,0/pci15ad,1976@10/sd@1,0
Specify disk (enter its number): Specify disk (enter its number):
UASOL1:#
5.Let me label the disk and naming the disk.
UASOL1:#format c1t1d0
selecting c1t1d0: quorum
[disk formatted]
FORMAT MENU:
disk - select a disk
type - select (define) a disk type
partition - select (define) a partition table
current - describe the current disk
format - format and analyze the disk
fdisk - run the fdisk program
repair - repair a defective sector
label - write label to the disk
analyze - surface analysis
defect - defect list management
backup - search for backup labels
verify - read and display labels
save - save new disk/partition definitions
inquiry - show vendor, product and revision
volname - set 8-character volume name
! - execute , then return
quit
format> fdisk
The default partition for the disk is:
a 100% "SOLARIS System" partition
Type "y" to accept the default partition, otherwise type "n" to edit the
partition table.
y
format> volname quorum
format> quit
UASOL1:#
6.You can see the same LUN on UASOL2 node as well.
UASOL2:#echo |format
Searching for disks...done
AVAILABLE DISK SELECTIONS:
0. c1t0d0 VMware,-VMware Virtual -1.0 cyl 1824 alt 2 hd 255 sec 63
/pci@0,0/pci15ad,1976@10/sd@0,0
1. c1t1d0 VMware,-VMware Virtual -1.0 cyl 508 alt 2 hd 64 sec 32 quorum
/pci@0,0/pci15ad,1976@10/sd@1,0
Specify disk (enter its number): Specify disk (enter its number):
UASOL2:#
7. Populate the disks in solaris cluster.
UASOL2:#cldev populate Configuring DID devices did instance 4 created. did subpath UASOL2:/dev/rdsk/c1t1d0 created for instance 4. Configuring the /dev/global directory (global devices) obtaining access to all attached disks UASOL2:# UASOL1:#cldev populate Configuring DID devices did instance 4 created. did subpath UASOL1:/dev/rdsk/c1t1d0 created for instance 4. Configuring the /dev/global directory (global devices) obtaining access to all attached disks UASOL1:#
8.Check the devices status.
UASOL1:#cldevice list -v DID Device Full Device Path ---------- ---------------- d1 UASOL2:/dev/rdsk/c1t0d0 d1 UASOL1:/dev/rdsk/c1t0d0 d4 UASOL2:/dev/rdsk/c1t1d0 d4 UASOL1:/dev/rdsk/c1t1d0 UASOL1:#cldev show d4 === DID Device Instances === DID Device Name: /dev/did/rdsk/d4 Full Device Path: UASOL1:/dev/rdsk/c1t1d0 Full Device Path: UASOL2:/dev/rdsk/c1t1d0 Replication: none default_fencing: global UASOL1:#
9.Add the d4 as quorum device in cluster.
UASOL1:#clquorum add d4 UASOL1:#
10.Check the Quorum status
UASOL1:#clq status
=== Cluster Quorum ===
--- Quorum Votes Summary from (latest node reconfiguration) ---
Needed Present Possible
------ ------- --------
2 3 3
--- Quorum Votes by Node (current status) ---
Node Name Present Possible Status
--------- ------- -------- ------
UASOL2 1 1 Online
UASOL1 1 1 Online
--- Quorum Votes by Device (current status) ---
Device Name Present Possible Status
----------- ------- -------- ------
d4 1 1 Online
UASOL1:#
We have successfully configured the quorum on two node Solaris cluster 3.3 u2.
How can we test quorum device is working or not ?
Just reboot any one of the node and you can see the voting status .
UASOL2:#reboot
updating /platform/i86pc/boot_archive
Connection to UASOL2 closed by remote host.
Connection to UASOL2 closed.
UASOL1:#
UASOL1:#clq status
=== Cluster Quorum ===
--- Quorum Votes Summary from (latest node reconfiguration) ---
Needed Present Possible
------ ------- --------
2 2 3
--- Quorum Votes by Node (current status) ---
Node Name Present Possible Status
--------- ------- -------- ------
UASOL2 0 1 Offline
UASOL1 1 1 Online
--- Quorum Votes by Device (current status) ---
Device Name Present Possible Status
----------- ------- -------- ------
d4 1 1 Online
UASOL1:#
We can see that UASOL1 is not panic by cluster. So quorum device worked well.
If you don’t have real SAN storage for shared LUN, you can use openfiler.
What’s Next ? We will configure resource group for failover local zone and perform the test.
